NH-XE21R1BSG 10.5KG HEAT PUMP DRYER
Consistent Drying Performance During Each Cycle
Powerful Linear Airflow is delivered through the drum holes to ensure even drying. The Big Lint Catcher at the front effectively captures lint to prevent build-up inside the machine and maintain drying performance.
Captures Lint. Prevents Build-Up
The Big Lint Catcher keeps airflow powerful throughout the drying cycle. Its large design traps more lint and allows air to move smoothly, helping maintain drying performance without frequent clogging.
Even, Thorough Drying
Delivers concentrated airflow across a wide area, circulating air evenly inside the drum for uniform drying.
Cleaner Condenser. Lasting Performance
Three-stage filtration captures large debris, fine lint, and dust. Keeping the condenser clean helps the machine last longer.
Hygienic Care, 99%*1 Bacteria Elimination
The dedicated Hygiene Dry course eliminates bacteria and reduce live house dust mites, providing gentle, hygienic care.
|
How do I install the Drying Rack? ① Expand the drying rack, then insert it into the drum at an angle. ② Hang the upper hook onto the drum's fixing hook. Make sure both support poles rest securely on the inner drum. Ensure it’s securely installed without wobbling. The rack comes with the dryer, so no additional purchase is needed. |
|
Technical Diagram
Specifications
| Loading Capacity | Drying Capacity (kg) | 10.5 | |
| Dimensions & Weight | Dimension (W x D x H) mm | 596 x 664 x 845 | |
| Drum Diameter (mm) | 525*374 | ||
| Door Inlet Diameter (W x H) mm | 310 | ||
| Net Weight (kg) | 55 | ||
| Basic Specification | Drying System | Heat Pump | |
| Drying Temperature | 69 ºC | ||
| Voltage | 220-240V | ||
| Frequency | 50Hz | ||
| Body Colour | Dark Black | ||
| Control Panel | Touch | ||
| Display Type | LED | ||
| Power Plug | S3 Type | ||
| Drying Features | MaxAir Dry | Yes | |
| Hygiene Dry | Yes | ||
| Tub Temperature Detection | Yes | ||
| Clothes Temperature Detection | Yes | ||
| Clothes Weight Detection | Yes | ||
| Convenient Features | Child Lock | Yes | |
| Big Lint Catcher | Yes | ||
| Triple Filtration | Yes | ||
| Easy Iron | Yes | ||
| Gentle Dry | Yes | ||
| Error Detection | Yes | ||
| Timer Dry | Yes | ||
| Drain Tank | Yes | ||
| Standard | Applied Regulation | IEC 61121 | |
| (EL) Energy Label | IEC 61121 | ||
| Safety | IEC 60335-1, IEC 60335-2-11 | ||
| Programmes | Number of Programmes | 12 | |
| Daily Dry | Yes | ||
| Cotton | Yes | ||
| Wool | Yes | ||
| Down Jacket | Yes | ||
| Quick Dry | Yes | ||
| Bedding | Yes | ||
| Sports | Yes | ||
| Delicates | Yes | ||
| Shirts | Yes | ||
| Synthetics | Yes | ||
| Warm Air | Yes | ||
| Optional Parts | Stacking Kit | Yes (N-SKT3B) | |
| Notes | *¹ Testing institution: Institute of Biotechnology / Bacteria elimination rate: Escherichia coli, Staphylococcus aureus up to 99％. / Report issue date: 30/Dec/2024 / Report reference No: 301224.4TN /VCCM. Test conditions apply. | ||
